2020 English 48 slides 719 views
PrintCSS workshop XMLPrague 2020
Andreas Jung gives a presentation on PrintCSS, which uses CSS to control pagination and layout when converting XML or HTML to PDF. He discusses various PrintCSS tools and their features, provides examples of how PrintCSS is used, and highlights areas that still need improvement, such as standardization, JavaScript support, image positioning, and hyphenation. The ecosystem of PrintCSS tools is still limited with few free and open source options.
Details
- Uploaded
- 13 February 2020
- Updated
- 16 November 2022
- Language
- English
- Slides
- 48
- Image size
- 2048x1448
- Views
- 719
- SlideShare ID
- 227856803
- Uploaded format
- PDF, PPTX
- Collected
- 2026-09-27
The description above is SlideShare's automatically generated summary, not the author's own text.
Source & completeness
- Content
- original + reconstructed
- Validation
- passed
- Slide text
- available (48 slides)
- Original files
- yes
- original.pdf
- original.pptx
Checksums (SHA-256)
original.pdf: c3743004b3b39fa03c222e76e995e6830260315abc89d4b70e570082919bf6dforiginal.pptx: d075f99d34170c16e4f224beabe1ba01a9cefd44f3e45d8943daaa59ace40c61
Slide images come from SlideShare's public renderings (2048x1448 px, WebP). Any file marked as reconstructed is assembled from those images and is not the author's original source file.
Full text of every slide
Text extracted by SlideShare from the slide images — may contain OCR errors. 48 of 48 slides have text.
1
PrintCSS
A Quick Walkthrough
Andreas Jung (ZOPYX)
info@zopyx.com
www.print-css.rocks
XMLPrague 2020
1 https:!//cutt.ly/jrIh5TI
2
AGENDA
‣ What is PrintCSS?
‣ Overview and tools
‣ Examples and usecases
‣ print-css.rocks project
‣ Basic and common "PrintCSS" features
‣ Demo time
‣ The missing parts and the bad parts
‣ Q & A
2
3
ANDREAS JUNG
‣ Master in Computer Science and Electrical Engineering
‣ background in electronic publishing since 1995
‣ freelancer since 2004
‣ large scale content management based on Plone CMS
‣ individual Python software development
‣ conversion workflows and publishing solutions
3
4
ANDREAS JUNG
‣Produce & Publish -
www.produce-and-publish.com
‣Collaborative content solutions based on Smashdocs -
www.creating-content-together.com
‣XML-Director foundation for XML CMS solutions -
www.xml-director.info
‣PrintCSS tutorial -
www.print-css.rocks
My projects:
4
5
What is "PrintCSS"?
5
6
WHAT IS "PRINTCSS"?
‣ "PrintCSS" = XML/HTML + CSS →PDF
‣ Browser "Print" is not "PrintCSS"
‣ "PrintCSS" deals with print specific aspects
‣ "paper" layout information
‣ counters and page numbers
‣ page areas
‣ pagination
‣ footnotes
‣ …
6
7
PRINTCSS AKA CSS PAGED MEDIA
‣ Draft: CSS Paged Media Module Level 3 (2018)
‣ Draft: CSS Generated Content for Paged Media Module (2014)
‣ Concepts
‣ Content: XML or HTML
‣ Design and layout: Cascading Stylesheets CSS
‣ Rule-based approach for defining all aspects of automatic typesetting
‣ separation between content and styling
‣ CSS Paged Media vs. XSL-FO
‣ easy approachability in general
‣ less complex than XSL-FO (CSS as foundation is common knowledge)
7
8
"CSS PAGED MEDIA" TOOLS
‣ WeasyPrint
‣ PrinceXML
‣ PDFreactor
‣ Antennahouse
‣ pdfChip
‣ Versatype (ex Vivliostyle)
8
9
TOOLS - PRICING VS FEATURES
9
10
TOOLS - PRICING VS FEATURES
Weasy
print
Prince PDFreactor
Antenna-
house
(pdfChip)
Personal
(commercial)
free 495 USD 1.250 USD
Personal
(non commercial)
free free free
Server free
3.800 USD
(∞ CPU?)
2.950 USD
(4 CPU)
5.000 USD
(1st CPU)
5.000 €
- 25.000 €
Server (EDU) free 1.900 USD 2.065 USD
10
11
Some examples
and use case
11
12
EXAMPLE: CATALOG PRODUCTION
Source: Bösch Preisliste via PDFreactor 12
13
EXAMPLE: LAYOUT-ORIENTED PUBLICATION
Source: Konzepte-IS via PDFreactor 13
14
EXAMPLE: INTERNATIONAL STUDIES
Source: Stiftung Wirtschaft und Politik (SWP) via Antennahouse14
15
EXAMPLE: DATABASE-DRIVING PUBLICATIONS
Source: EUROPEAN PHARMACOPOEIA via PDFreactor15
16
‣ vendor-neutral information about "PrintCSS"
‣ information about tools
‣ tested tools:
‣ PrinceXML
‣ Antennahouse
‣ PDFreactor
‣ WeasyPrint
‣ tutorial and lessons
‣ "PrintCSS" related resources
‣ www.print-css.rocks
16
17
LESSONS
17
18
CONVERTER RESULTS
18
19
HTML INPUT
19
20
CSS INPUT
20
21
Basic and common
"PrintCSS" features
21
22
MULTI-COLUMNS AND FOOTNOTES
‣ ✅ multi-column support
‣ ✅ footnote support
‣ footnotes within the
same column
‣ ✅ AH, Prince
‣ 🚫 PDFreactor
22
23
BASELINE GRID
‣Placement of text within a given grid
‣supported by all tools
‣vendor-specific implementation
23
24
FLOATS (1/3)
‣ (automatic) moving of block elements (images,
tables, inserts)
‣ within the current page
‣ within the current column set
‣ to the next page
‣ colspan optional
‣ AH: most complete, but complex extension
‣ Prince, PDFreactor: partial support
24
25
FLOATS (2/3)
25
26
FLOATS (3/3)
26
27
IMAGES
‣ Bitmap images: JPEG, PNG, GIF, TIFF
‣ Vector formats: PDF, SVG
‣ Color spaces: RGB, CMYK, ICC profiles
‣ Problems:
‣ auto-placement
‣ automatic (down)-scaling
27
28
PAGINATION
‣ automatic pagination
‣ pagiation hints through CSS
‣ support for orphans and widows
div.chapter {
page-break-after: always;
}
table {
page-break-inside: avoid;
}
div.chapter {
page-break-after: never;
}
div.chapter {
orphans: 2;
widows: 3;
}
28
29
FONTS
‣ Support for all common font formats
‣ Opentype
‣ Truetype
‣ Google webfonts
‣ Fonts embedded by default into the PDF
29
30
RTL, VERTICAL RL, ASIAN CONTENT
‣ General support for right to left
‣ General support for vertical RL (JP/CN)
‣ Special fonts usually required with required code points
30
31
Demo time
What do you want to see?
31
32
The missing parts.
The bad parts.
32
33
THE "STANDARD" (1/2)
‣ the W3C "CSS Paged Media" standard defines the
foundation for "PrintCSS"
‣ standards and specifications are years-old, draft status
‣ status of drafts unclear (unmaintained, work-in-
progress, discontinued?)
‣ many vendor specific extensions (development usually
driven by customer needs)
‣ limited cross-platform compatibility and interoperability
33
34
THE "STANDARD" (2/2)
‣ conflicting implementations
‣ conflicting interpretations of the "standard"
‣ (missing?) test suite(s)
‣ support of modern/new CSS features
‣ in browsers: fast adaptation
‣ in PrintCSS tools: moving (very) slowly
34
35
(CONSISTENT) JAVASCRIPT SUPPORT
‣ ✅ PrinceXML and PDFreactor
‣ 🚫 Antennahouse
‣ support only for selected JavaScript modules
‣ missing rendering API for hooking into the rendering process
35
36
FLEX BLOCK AND GRID SYSTEMS
‣ Flex block:
‣ ✅ PrinceXML and PDFreactor
‣ 🚫 Antennahouse
Source: https://css-tricks.com/
36
37
🚫 SIDE NOTES
Source: CSS Tricks
‣ Antennahouse: own extension
‣ PDFreactor: CSS + JavaScript
‣ PrinceXML: CSS
‣ 🚫 Challenges:
‣ float to inside/outside
‣ side notes in multi-column
environments
‣ positioning
37
38
🚫 IMAGE POSITIONING (1/2)
‣ Problem:
‣ an image does not fit on the remaining page or
into the remaining column
‣ avoid blank areas
‣ Solutions:
‣ float image on next page or into next column
‣ scale image down to remaining space in column or
on page
38
39
🚫 IMAGE POSITIONING (2/2)
!/* Prince !*/
#globe {
width: 100%;
float: column-top next;
column-span: 2;
}
!/* Prince !*/
#globe {
width: 100%;
float: column-top next;
}
39
40
🚫 FIT TEXT INTO A GIVEN BOX
‣ ✅ PDFreactor: Javascript
‣ ✅ Antennahouse:
-ah-overflow-condense: font-stretch | font-size
| letter-spacing;
‣ 🚫 PrinceXML
40
41
🚫 ISSUES WITH HYPHENATION
‣ hyphenation quality differs by language and tool
‣ breaking of long words/terms (e.g. URLs) often an issue
‣ no standard for hyphenation exceptions
‣ injecting and maintaining hyphenation hints
(e.g. soft-hyphens) is a pain
41
42
🚫 ISSUES WITH TABLES
‣ tables split over multiple pages
‣ control over repeating headers and footers
‣ custom table captions ("continued….")
‣ controlling page breaks with row spans
42
43
🚫 MARGIN BOXES/RUNNING ELEMENTS
‣ page margin boxes:
‣ text only, no HTML
‣ one style per margin box
‣ running elements:
‣ content removed from content area
‣ content place in margin box
‣ content duplication often needed
‣ styling of mixed running elements and
generated content is a major pain
43
44
🚫 EXCLUSIONS
https://www.w3.org/TR/css3-exclusions (2015)
Source: Vivliostyle
44
45
🚫 DEVELOPING WITH PRINTCSS
‣ no real development tools
‣ rendering process is a blackbox process
‣ content + styles in, PDF out
but what is happening inside and why?
‣ few tracing options for the mortal PrintCSS developer
‣ usually a lengthy, iterative process
‣ no/little support for introspecting the rendering process
‣ no/little support for influencing the rendering process
besides CSS
45
46
THE ECOSYSTEM
‣ CSS Paged Media tools:
‣ few commercial tools
‣ even fewer non-commercial, free tools
‣ limited options
‣ in-depth evaluation needed for advanced projects
‣ at one point you need to decide and pick one tool
46
47
Questions?
47
48
Thank you!
www.print-css.rocks
www.zopyx.com
Andreas Jung <info@zopyx.com>
48
